Mipi Tester – UFS & EMMC Chip Programmer
MOORC MIPITESTER/MiPi Box Pro Programmer for EMMC and UFS is a UFS / eMMC device programmer designed to read / write and repair data using both the ISP and Direct method. The set includes UFS (254/153) and eMMC / eMCP (153-169, 254, 221, 162-186) adapters.
Features:
UFS / UMCP / ISP – Data transfer speed
- UFS/UMCP
- UFS 2.0 / 2.1 / 3.0 / 3.1 supported
- HS-G2 high speed mode
- 80-130 MB/s (writing) / 100-180 MB/s (reading)
- for 100 MB higher speed you need to use USB 3.0 + high speed SSD
- UFS ISP
Flying Line Mode PWM-G1 6-15MB/s (reading / writing)
EMMC/EMCP – Data transfer speed
- EMMC 4.5 / 5.0 / 5.1 supported
- HS200 80-120MB/s (write) / 120MB/s (read)
- EMMC ISP 5-15MB/s (read / write)
Upgrade NAND / PCIE / NVME / NOR / SPI / I2C Flash
- Supports UFS/UMCP dedicated descriptors, attributes, flags and other chip initialization and advanced settings
- LUN cutting
- Read / Write / Specify boot area
- Read / Write EMMC/EMCP User Area and BOOT1/2
- Read / Write advanced RPMB, GPP
- Enhanced Area settings
- Voltage output (VCC, VCCQ) 1.1 V – 3.3 V + intelligent short circuit protection
Supported BGA:
- UFS BGA 254
- UFS BGA 153
- eMMC BGA 153-169
- eMMC BGA 254
- eMMC BGA 221
- eMMC BGA 162-186
Package Content:
MiPi Box Pro – 1 pc.
MiPi eMMC/UFS ISP Adapter S2 ISP- 1 pc.
MiPi USB 3.0 Cable – 1 pc.
MiPi DC5V Power Cable – 1 pc.
MiPi UFS 254/153 Socket Adapter- 1 pc.
MiPi ANDROIDKING eMMC/UFS Socket Adapter – 11 in 1 set:
- AK-UFS BGA 221 – 1 pc.
- AK-eMMC BGA 254-BGA95 – 1 pc.
- AK-UFS BGA 153 – 1 pc.
- AK-eMMC BGA 153-169 – 1 pc.
- AK-UFS BGA 254 – 1 pc.
- AK-eMMC BGA 162-186 – 1 pc.
Frames (4 pcs):
- 7,5*9
- 11*10
- 12*15
- 12*16
